Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS08B
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS08B Specifications
- Model: CM3PMS08B
- Type: Mushroom head push button mechanical valve (3/2-way)
- Port size: G1/8 (M5 optional, with adaptor)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Operation type: Mechanical latching with manual reset
- Body material: Stainless steel (SUS303) with anodized aluminum alloy
- Seal material: NBR (Nitrile) / FKM (Fluorocarbon) optional
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Actuation force: 30-50N (mechanical lock release force)
- Contact rating: 5A 250VAC (gold-plated contacts)
- Protection rating: IP67 (dust/water resistant)
- Weight: 200g ±5% (including mounting hardware)
- Dimensions: 60mm(L) × 40mm(W) × 30mm(H) (button protrusion: 15mm)
Emergency stop valve with positive mechanical latching mechanism, featuring a bright red mushroom head compliant with ISO 13850 safety standards. The dual-color LED status indicator (red/green) provides clear visual feedback. Rugged zinc alloy construction withstands 1 million+ operations, with tamper-resistant security screws for safety compliance.
- Emergency stop systems in CNC machines
- Safety interlocks for robotic workcells
- Pressurized equipment emergency release
- Conveyor line emergency shutdown
- Hydraulic system safety override
Installation requirements:
Mount within 45° of vertical plane. Requires 2.5mm² minimum wiring for safety circuits.
Test monthly by pulling along 8 possible angular directions (IEC 60947-5-5 compliant).
- EN ISO 12100:2010 (Risk assessment)
- EN 60204-1 (Electrical safety)
- PL d / Category 3 per ISO 13849-1
| Property | Property Value |
|---|---|
| sku | CM3PMS08B |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
