Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX06-P1
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PMX06-P1
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The CM3B, CM3L, CM3V, and CM3R series require external mechanisms to provide actuation force for directional switching, making them suitable for position detection or limit switch applications.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
Installation guidelines:
Mount vertically with ≤5° tolerance. Apply thread sealant on port connections.
Perform monthly function tests - full depression should completely block airflow within 0.3s.
Compatible with 40-75μm filtration systems.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX06-P1 Large Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMX06-P1
- Type: 3/2-way normally closed (mechanical spring return)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.1–0.9 MPa
- Flow capacity: 450 NL/min (at 0.5 MPa)
- Actuation force: 40-50N (mushrooм head requires 8-12mm travel)
- Body material: Anodized aluminum alloy (button: engineering plastic with UV coating)
- Seal material: High-grade NBR (nitrile) rubber
- Temperature range: -20℃ to 80℃ (with dry air)
- Weight: 215g ±5g (including mounting hardware)
- Dimensions: 50mm(W) × 50mm(H) × 30mm(D) (excluding button protrusion)
- Mounting: 22mm panel cutout (DIN standard)
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
- Emergency stop compliance: Meets ISO 13850 safety standards
Robust emergency stop valve featuring a 38mm diameter mushroom head with dual-stage engagement (partial press for pause, full press for emergency cutoff). The yellow-red color scheme ensures high visibility, while the twist-to-reset mechanism prevents accidental reactivation. Includes integrated dust shield around actuator stem and stainless steel return spring.
Typical Applications:
- Production line emergency stop stations
- Packaging machinery safety interlocks
- CNC machine tool safety circuits
- Automated warehouse conveyor systems
- Plastic injection molding machine guards
Installation guidelines:
Mount vertically with ≤5° tolerance. Apply thread sealant on port connections.
Perform monthly function tests - full depression should completely block airflow within 0.3s.
Compatible with 40-75μm filtration systems.
| Property | Property Value |
|---|---|
| sku | CM3PMX06-P1 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
