Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP05B
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PP05B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. The CM3B, CM3L, CM3V, and CM3R series require externally applied force for valve actuation, making them ideal for position detection or as limit switches.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
Installation note:
Ensure button axis alignment with operator's natural hand position (±5° tolerance).
Apply silicone grease (ISO 12096 compliant) to sliding surfaces during maintenance.
Maximum recommended operation frequency: 60 cycles/minute.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Convex Head Push Button Mechanical Valve CM3PP05B Specifications
- Model: CM3PP05B
- Type: 3/2-way normally closed (manual reset)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.7 MPa
- Temperature range: -5℃ to 60℃
- Seal material: NBR rubber (fluorine rubber optional)
- Weight: 205g ±5g
- Dimensions: 50mm(L) × 25mm(W) × 40mm(H)
- Mounting style: Direct panel mounting with M5 screws
- Protection rating: IP40 (dust-protected)
- Operating force: ≤1.5N at 0.5MPa
- Flow capacity: 350 NL/min (ANR, at ΔP=0.1MPa)
- Actuation type: Mechanical latching mechanism
- Body material: PA66 reinforced nylon (UL94 V-2)
Robust manual override valve with tactile convex button design for precise tactile feedback in emergency stop or manual control scenarios. Features anti-vibration lock mechanism and wear-resistant stem structure. Compatible with ISO 15407-1 standards for pneumatic components.
Typical Applications:
- Emergency stop systems in packaging machinery
- Manual mode override in automated production lines
- Safety interlocks for medical equipment
- Process control in semiconductor manufacturing
- Mobile hydraulic platform controls
Installation note:
Ensure button axis alignment with operator's natural hand position (±5° tolerance).
Apply silicone grease (ISO 12096 compliant) to sliding surfaces during maintenance.
Maximum recommended operation frequency: 60 cycles/minute.
Special Features:
- Double-seal structure prevents internal leakage
- Stainless steel spring (SUS304) for corrosion resistance
- Audible click feedback at 55-65dB operation noise level
- 100,000+ cycle durability tested
| Property | Property Value |
|---|---|
| sku | CM3PP05B |
| Position | 3-Port 2-Position |
| Port Size | M5 |
