Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP05G
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP05G Push Button Mechanical Valve Specifications
- Model: CM3PP05G
- Type: 3/2-way normally closed (manual push-button override)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 450 L/min (ANR)
- Actuation force: 2.5-3.5 N (button press)
- Valve body material: Glass fiber reinforced PBT
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 82g ±2g
- Dimensions: 38mm(W) × 26mm(H) × 58mm(L)
- Mounting orientation: Any (360° rotatable button)
- Manual override: Lockable position with ±30° rotation
- Cycle life: ≥500,000 operations
- Protection rating: IP65 (dust-tight & protected against water jets)
Robust mechanical valve featuring tactile feedback and emergency manual control. The ergonomic convex button design enables glove-friendly operation in harsh environments. Integrated locking mechanism allows temporary flow state maintenance without continuous pressure. Compatible with ISO 15407-1 standards for pneumatic valves.
- Emergency stop override in automated assembly lines
- Manual mode switching for pneumatic testing benches
- Mobile equipment requiring manual air circuit control
- Safety interlocks in packaging machinery
- Training systems for pneumatic circuit education
Installation note:
Ensure compressed air cleanliness class ISO 8573-1:2010 [7:4:4] or better.
For vertical mounting, orient button axis within 45° of horizontal plane
for optimal tactile feedback. Lubricate seals with PAG oil if used below -10℃.
| Property | Property Value |
|---|---|
| sku | CM3PP05G |
| Position | 3-Port 2-Position |
| Port Size | M5 |
