Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06-P3
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PP06-P3
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. The CM3B, CM3L, CM3V, and CM3R series require externally applied force for valve actuation, making them ideal for position detection or as limit switches.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
Installation note:
Ensure proper tactile feedback by maintaining 0.5-1mm button protrusion above panel surface.
For vertical mounting, position cable entry downward to prevent dust accumulation.
Lubricate pivot points with ISO VG32 hydraulic oil during annual maintenance.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06-P3 Specifications
- Model: CM3PP06-P3
- Type: 3/2-way normally closed (mechanical spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa
- Actuation force: 3.5–4.5 N
- Flow capacity (Cv value): 0.45
- Weight: 180g ±5g
- Dimensions: 54mm(L) × 34mm(W) × 34mm(H)
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP65 (dust-tight & protected against water jets)
- Mounting type: Direct panel mounting (requires 16mm cutout diameter)
- Operating cycles: ≥1,000,000 cycles (at rated pressure)
Robust manual override valve with emergency stop functionality, featuring a distinctive red mushroom head for quick identification. The zinc-plated steel spring ensures reliable return action even in high-vibration environments. Designed for systems requiring manual intervention without electrical connections.
Typical Applications:
- Emergency stop circuits in production line machinery
- Manual override for automated assembly systems
- Safety interlocks in press machinery
- Pneumatic system maintenance bypass controls
- Training simulators for industrial equipment operation
Installation note:
Ensure proper tactile feedback by maintaining 0.5-1mm button protrusion above panel surface.
For vertical mounting, position cable entry downward to prevent dust accumulation.
Lubricate pivot points with ISO VG32 hydraulic oil during annual maintenance.
| Property | Property Value |
|---|---|
| sku | CM3PP06-P3 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
