Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06B
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Button Head Mechanical Valve CM3PP06B Specifications
- Model: CM3PP06B
- Type: 3/2-way manual reset mechanical valve (push-button operation)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Operating force: ≤5N (button actuation)
- Body material: Anodized aluminum alloy
- Seal material: High-grade HNBR rubber
- Temperature range: -20℃ to 80℃ (with silicone seals optional up to 120℃)
- Flow capacity: 850 l/min (ANR)
- Weight: 320g ±5g
- Dimensions: 58mm(L) × 36mm(W) × 72mm(H) (excluding button protrusion)
- Button stroke: 4mm with ±0.3mm tolerance
- Mounting options: Panel mount (front) with M20×1.5 locknut
- Protection rating: IP67 (dust/water resistant)
- Cycle life: ≥500,000 operations
Robust manual override valve featuring tactile feedback and anti-vibration design. The mushroom-shaped emergency stop button meets ISO 13850 safety standards with positive latching mechanism. Integrated dust shield prevents particulate ingress, while the dual-color (black body/yellow button) design ensures high visibility in industrial environments.
- Emergency stop systems in pneumatic circuits
- Manual override for automated production lines
- Safety interlocks in press machinery
- Mobile equipment control stations
- Process control manual reset applications
Installation note:
Requires 25mm minimum panel thickness for secure mounting.
Apply thread sealant on NPT ports (tapered threads).
Perform monthly button actuation tests to maintain mechanical reliability.
| Property | Property Value |
|---|---|
| sku | CM3PP06B |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
