Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06Y
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Convex Head Push Button Mechanical Valve CM3PP06Y Specifications
- Model: CM3PP06Y
- Type: 3/2-way normally closed push button type (mechanical operation)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: Cv 0.08 (at 0.5 MPa)
- Valve body material: Brass (Nickel-plated)
- Seal material: NBR (Nitrile rubber)
- Operating temperature: -5℃ to 70℃ (23℉ to 158℉)
- Button stroke: ~5mm
- Mounting style: Panel mounting (12mm cutout diameter)
- Mechanical life: ≥1,000,000 cycles
- Weight: 180g ±5% (including accessories)
- Dimensions: 30mm(W) × 30mm(D) × 42mm(H)
- Protection rating: IP40 (front face IP65 when properly installed)
- Manual override: Positive tactile feedback with lockable design
Robust manual override valve featuring a distinctive convex button design for enhanced tactile operation. The chrome-plated brass construction ensures corrosion resistance in humid environments. Requires no electrical connection, making it ideal for emergency stop functions or manual control stations. Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency stop circuits in production lines
- Manual mode override in automated machinery
- Training equipment for pneumatic system education
- Mobile hydraulic/pneumatic hybrid systems
- Cleanroom environments requiring spark-free operation
Installation note:
Apply ≤5N operating force to prevent internal spring fatigue.
For vertical mounting, ensure button faces downward to prevent
debris accumulation. Lubricate pivot points every 50,000 cycles
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | CM3PP06Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
