Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP08R
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Convex Head Push Button Mechanical Valve CM3PP08R Specifications
- Model: CM3PP08R
- Type: 3-position (Open/Close/Exhaust) manual mechanical valve
- Operation style: Push-button actuation with spring return
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 450 L/min (ANR)
- Actuation force: 3.5N ±0.5N
- Body material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃
- Weight: 120g ±5g
- Dimensions: 30mm(W) × 20mm(D) × 40mm(H)
- Mounting style: Panel mount (6.5mm panel cutout required)
- Protection rating: IP54 (dust protected, splash resistant)
- Cycle life: ≥500,000 operations
Robust manual override valve with tactile feedback, featuring a distinctive convex button design for gloved-hand operation. The chrome-plated brass construction ensures corrosion resistance in humid environments. Integrated O-ring sealing prevents air leakage during emergency stops. Requires 5-40μm filtered compressed air.
- Emergency stop systems in automated production lines
- Manual override for pneumatic cylinder control
- Safety purge controls in chemical processing equipment
- Maintenance bypass in packaging machinery
- Test bench pressure regulation systems
Installation note:
Ensure button travel path clearance (minimum 15mm above panel surface).
Apply thread sealant to port connections and torque to 1.2-1.5N·m.
For vertical mounting, orient exhaust port downward.
| Property | Property Value |
|---|---|
| sku | CM3PP08R |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
