Airtac CM3R Roller Lever Mechanical Valve CM3R08
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations for versatile operational conditions;
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-position mounting capability enables flexible installation;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate robust metal actuators for enhanced durability and operational reliability;
6. CM3PMS and CM3PMX series integrate metal protective shrouds to prevent accidental button contact and ensure fail-safe operation.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3R Roller Lever Mechanical Valve
AirTAC CM3R Roller Lever Mechanical Valve CM3R08 Technical Details
- Model: CM3R08
- Type: 3-way (3/2) roller lever operated mechanical valve
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.7 MPa
- Max flow rate: 350 L/min (ANR)
- Actuation force: 3.5N±1N at lever tip
- Lever stroke: 3.5mm±0.5mm
- Body material: Nickel-plated brass
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 80℃ (with silicone seals optional for -20℃ to 90℃)
- Weight: 180g±5g
- Dimensions: 53mm(L) × 34mm(W) × 65mm(H) (excluding lever protrusion)
- Mounting: Direct piping or sub-base (ISO 15407-1 compatible)
- Protection rating: IP67 (dustproof and waterproof when installed)
Mechanically actuated valve with roller lever for smooth operation and reduced wear. Features dual-position memory function and bidirectional flow control. The roller tip reduces sliding friction by 60% compared to standard lever valves, enabling over 5 million cycles lifespan. Requires 5-40μm filtered compressed air.
- Position detection in automated assembly lines
- Emergency stop mechanisms in packaging machinery
- Workpiece clamping confirmation in CNC fixtures
- Safety door interlocks in industrial ovens
- Material handling equipment limit switches
Installation guidelines:
Mount with lever axis perpendicular to actuation direction.
Maintain 0.5-1mm gap between roller and trigger surface.
Lubricate pivot point every 500,000 cycles using ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | CM3R08 |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
