Airtac M3D Short Lever Type Mechanical Valve M3D11006
1. Exhaust ports integrated into the body facilitate silencer installation, reducing noise emissions and environmental contamination;
2. M3B, M3R, and M3L series feature external force-driven actuation mechanisms, compatible with position detection systems or limit switch applications;
3. M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series incorporate manual override mechanisms with multi-configuration actuator heads for versatile operational requirements;
4. Spool-type construction ensures consistent actuation force independent of working pressure (backpressure-resistant design), enhanced by internal ring seals for leak-tight performance and responsive directional switching;
5. Maintenance-free operation without lubrication requirements;
6. Multi-position mounting capability enables flexible installation configurations;
7. M3C, M3D, M3Y, M3R, and M3I series employ metal actuator heads for extended service life and enhanced operational reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: M3D
AirTAC M3D Short Handle Mechanical Valve M3D11006 Specifications
- Model: M3D11006
- Type: 3/2-way manual override mechanical valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Filtered compressed air (lubricated or non-lubricated)
- Flow capacity: 650 L/min (ANR)
- Weight: 180g ±5%
- Dimensions: 45mm(L) × 30mm(W) × 40mm(H)
- Body material: Aluminum alloy (anodized finish)
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃ (with intermittent peaks at 100℃)
- Manual override stroke: 8mm ±0.5mm
- Actuation force: ≤3N
- Mounting options: Direct piping or sub-base mounting
- Protection rating: IP54 (standard), IP67 available on request
Compact manual override valve with ergonomic mushroom head design for emergency operation. Features double-seal structure for leak prevention and wear-resistant guides for 500,000+ cycle durability. Compatible with ISO 15407-1 standards. Requires 5μm filtered air with max 1mg/m³ oil content.
- Emergency stop systems in production lines
- Jig clamping mechanisms in CNC machinery
- Safety override in automated assembly units
- Manual control stations for pneumatic testing rigs
- Mobile equipment maintenance bypass systems
Installation note:
For vertical installations, ensure manual actuator faces accessible direction.
Apply thread sealant on port connections (PTFE tape not recommended).
Maximum allowable vibration: 4.9m/s² at 10-60Hz.
| Property | Property Value |
|---|---|
| sku | M3D11006 |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
