Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM11006R
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM Mushroom Head Push Button Mechanical Valve M3PM11006R Specifications
- Model: M3PM11006R
- Type: 3/2-way normally closed (manual reset)
- Operation type: Mechanical latching with emergency stop function
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.1–0.9 MPa
- Max flow rate: 450 NL/min
- Actuation force: 50-60N (manual operation)
- Body material: Anodized aluminum alloy
- Seal material: High-grade HNBR rubber
- Temperature range: -10℃ to 80℃
- Weight: 215g ±5g
- Dimensions: 54mm(L) × 54mm(W) × 48mm(H)
- Mounting pattern: Compliant with ISO 15218 standard
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Industrial-grade emergency stop valve featuring twist-to-reset mushroom head design with positive latching mechanism. The yellow-red color scheme complies with ISO 13850 safety standards. Integrated with dual-stage sealing technology for leak-free performance in high-vibration environments.
- Production line emergency stop systems
- Plastic injection molding machine safety circuits
- Robotic cell safety interlocks
- Press brake machine pneumatic controls
- Packaging equipment emergency air cutoff
Installation guidelines:
Must be installed within 1m of operator position per ISO 12100 safety requirements.
Requires monthly functional testing - pull ring must return freely without binding.
Use thread sealant on port connections (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | M3PM11006R |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
