Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM21006G
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM21006G Mushroom Head Push Button Mechanical Valve Specifications
- Model: M3PM21006G
- Type: 3/2-way normally closed (mechanical spring return)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.05–0.8 MPa
- Operation force: 50N ±10% (manual emergency stop activation)
- Reset method: Twist-to-release manual reset
- Body material: Anodized aluminum alloy (hard oxide film thickness ≥15μm)
- Seal material: High-wear NBR rubber (70±5 Shore A)
- Temperature range: -10℃ to 80℃ (no ice formation)
- Mechanical life: ≥500,000 cycles
- Protection rating: IP67 (dust/water resistant)
- Weight: 215g ±5% (including mounting hardware)
- Dimensions: 48mm(D) × 48mm(W) × 58mm(H) (excluding button protrusion)
- Button diameter: 40mm (standard red mushroom head)
- Mounting: M12 × 1.25 threaded base with anti-rotation tabs
Emergency stop valve with positive mechanical latching mechanism, featuring a highly visible red mushroom button for safety-critical applications. The zinc-plated steel spring ensures reliable reset operation even in high-vibration environments. Includes integrated mounting slots for DIN rail or panel installation.
- Industrial machinery emergency stop systems
- Automated production line safety interlocks
- Packaging equipment emergency air circuit cutoff
- Robotic workcell safety door controls
- Press machine two-hand control systems
Installation note:
Mount within 45° of vertical position for optimal button operation.
Apply 0.5-0.8Nm torque during installation - over-tightening may deform sealing surfaces.
Perform monthly function tests in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | M3PM21006G |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
