Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM21008R
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM Mushroom Head Push Button Mechanical Valve M3PM21008R Specifications
- Model: M3PM21008R
- Type: 3/2-way normally closed (manual reset)
- Operation: Mechanical latching with emergency stop function
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.2–0.8 MPa
- Max flow rate: 450 L/min
- Actuation force: 30-50N (yellow mushroom head)
- Reset method: Twist-to-release mechanism
- Body material: Anodized aluminum alloy
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -10℃ to 80℃
- Weight: 220g ±5g
- Dimensions: 54mm(D) × 54mm(W) × 83mm(H)
- Protection rating: IP67 (dust/water resistant)
- Mounting: Panel mount with M20 locknut
Emergency stop valve with positive mechanical latching, featuring a highly visible yellow mushroom head for rapid system shutdown. The twist-release mechanism ensures controlled reset operations. Optimized for high-vibration environments with brass internal guides and corrosion-resistant coatings.
- Industrial machinery emergency stop systems
- Assembly line safety interlocks
- Press brake safety controls
- Robotic cell emergency cutoff
- Packaging line emergency venting
Installation note:
Requires 45mm minimum panel thickness for secure mounting.
Perform monthly latch mechanism lubrication using silicone-free grease (ISO VG 10 equivalent).
Ensure 360° accessibility for emergency operation.
| Property | Property Value |
|---|---|
| sku | M3PM21008R |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
