Airtac M5Y Rocker Type Mechanical Valve M5Y11006
2. M5B/M5R/M5L series utilize externally supplied actuation force for switching, enabling position detection or travel switch applications.
3. M5C/M5D/M5Y/M5PF/M5PM/M5PP/M5PL/M5HS series feature manual operation with diversified actuator configurations, optimized for diverse operating conditions.
4. Spool-type structure ensures consistent control force independent of working pressure (zero backpressure effect). Internal sealing design guarantees superior leak-tightness and responsive directional switching.
5. Oil-free lubrication system eliminates maintenance requirements.
6. Multiple mounting orientations enhance installation flexibility and operational convenience.
7. Metal actuators in M5C/M5D/M5Y/M5R/M5L series ensure extended service life with reinforced reliability and stability.
Category: Mechanical Valves | Brand: Airtac | Series: M5Y
AirTAC M5Y11006 Lever-Operated Mechanical Valve Specifications
- Model: M5Y11006 (Lever Return Type)
- Type: 3/2-way normally closed mechanical valve
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Actuation force: ≤5N lever operation
- Valve body material: PA66+30%GF (glass reinforced nylon)
- Seal material: NBR/HNBR (nitrile rubber)
- Temperature range: -5℃ to 80℃
- Flow rate: 350 NL/min (at 0.5 MPa)
- Weight: 180g ±5%
- Dimensions: 45mm(L) × 30mm(W) × 25mm(H)
- Mounting style: Direct piping or sub-base mounting
- Response time: ≤50ms
- Protection rating: IP65 (dust-tight & water jet resistant)
Manual override valve with ergonomic lever design for tactile operation in emergency stop scenarios or maintenance cycles. Features corrosion-resistant construction with glass-fiber reinforced body and precision-machined brass core. Includes built-in silencer (optional) for noise reduction below 70dB(A). Compatible with ISO 15407-1 standards.
- Emergency stop systems in assembly line conveyors
- Manual override for automated packaging machinery
- Safety interlocks in woodworking equipment
- Pneumatic circuit debugging & maintenance
- Mobile hydraulic platform controls
Installation guidelines:
- Mount lever within 30° of vertical plane for optimal force application
- Use 5-40μm filtered air with ISO 8573-1:2010 Class 3.4.2 purity
- Apply thread sealant only on male threads (PT/G specifications)
- Lubricate pivot point with ISO VG32 hydraulic oil quarterly
| Property | Property Value |
|---|---|
| sku | M5Y11006 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
