Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM-08-B
$20.90
Regular price
$28.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
S3PM-08-B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The S3B, S3R, S3L, and S3V series require external mechanism-provided actuation force for directional switching, ideal for position sensing or limit switch applications.
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
Installation notes:
Requires 45° pull-out angle for proper cable routing. Perform monthly
functional tests. Use thread sealant on port connections. Avoid mounting
near high-vibration sources (≥50Hz).
Safety notice:
Always connect in series with control circuit. Test reset function
after each activation. Replace immediately if button shows
>0.5mm lateral play.
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM-08-B Mushroom Head Push Button Mechanical Valve Technical Details
- Model: S3PM-08-B
- Type: Push-lock emergency stop valve (mechanical reset)
- Button type: Mushroom head (red/yellow dual-color optional)
- Body material: Anodized aluminum alloy + PBT plastic
- Operating force: 1-3N (manual reset force ≥5N)
- Actuation travel: 4mm±0.5mm
- Port size: 1/8" NPT (G1/8 adapter included)
- Max pressure: 1.0 MPa
- Contact configuration: SPDT (1NO+1NC)
- Contact rating: 5A 250VAC (resistive load)
- Protection rating: IP67 (dust/water resistant)
- Temperature range: -25℃ to +80℃
- Mounting: 22mm panel cutout (M18×1.5 thread base)
- Weight: 198g ±5g (with mounting accessories)
- Dimensions: Ø40mm (head) × 60mm(H) × 22mm(base thickness)
Emergency safety valve with twist-to-reset mechanism and dual-color status indication (red=activated, yellow=standby). Features anti-vibration locknut design and overstroke protection. Meets ISO 13850 safety standards with positive-opening contacts for fail-safe operation.
Typical Applications:
- Emergency stop systems for CNC machines
- Safety interlocks in robotic workcells
- Press brake machine safety controls
- Assembly line emergency shutdown
- Packaging equipment safety stations
Installation notes:
Requires 45° pull-out angle for proper cable routing. Perform monthly
functional tests. Use thread sealant on port connections. Avoid mounting
near high-vibration sources (≥50Hz).
Safety notice:
Always connect in series with control circuit. Test reset function
after each activation. Replace immediately if button shows
>0.5mm lateral play.
| Property | Property Value |
|---|---|
| sku | S3PM-08-B |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
