Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P11A
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P11A Specifications
- Model: S3PM05-P11A
- Type: 3/2-way normally closed (mechanical actuation)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Actuation force: 3.5–5.5 N
- Flow coefficient (Cv): 0.45
- Body material: Anodized aluminum alloy (hard coating)
- Seal material: High-grade NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃ (with dry air)
- Mounting style: Panel mount (requires 22.5mm cutout)
- Protection rating: IP67 (dust/water resistant)
- Weight: 180g ±5g
- Dimensions: 42mm(D) × 42mm(W) × 56mm(H)
- Thread engagement depth: 10mm (for panel mounting)
- Reset mechanism: Manual twist-release with 45° rotation
Emergency-stop style mechanical valve featuring a highly visible red mushroom head with yellow base. Engineered for fail-safe operation in harsh environments, with stainless steel internal springs and wear-resistant guide pins. The dual-color design meets ISO 13850 safety standards for emergency stop devices. Requires lubrication-free operation and compatible with ISO 8573-1:2010 Class 3 compressed air.
- Emergency stop circuits in CNC machinery
- Safety interlocks for press machines
- Pneumatic system manual override stations
- Assembly line emergency ventilation control
- Food processing equipment safety systems
Installation note:
Mount with 1.2–1.5 N·m torque using included M18×1.5 locknut.
Perform monthly functional tests - the button should fully travel
8mm with audible click. Avoid mounting near high-vibration sources.
| Property | Property Value |
|---|---|
| sku | S3PM05-P11A |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
