Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P12A
$5.80
Regular price
$13.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
S3PM05-P12A
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The S3B, S3R, S3L, and S3V series require external mechanism-provided actuation force for directional switching, ideal for position sensing or limit switch applications.
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
Installation note:
Ensure full button travel clearance (minimum 5mm vertical space above actuator).
Perform monthly functional tests and lubricate rotating parts with silicone grease (ASG-15 recommended).
Safety notice:
This is a mechanical safety device - must be installed in series with electrical safety relays.
Never bypass or modify the reset mechanism.
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P12A Specifications
- Model: S3PM05-P12A
- Type: 3/2-way normally closed (manual reset)
- Operation type: Mechanical latching with emergency stop function
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.1–0.7 MPa
- Operating temperature: -5℃ to 60℃
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR (nitrile rubber)
- Actuation force: 30-50N (manual push)
- Reset method: Twist-to-release mechanism
- Weight: 80g ±5%
- Dimensions: 40mm(L) × 40mm(W) × 22.5mm(H)
- Mounting: Panel mounting with M12 lock nut
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency stop valve with positive mechanical latching, featuring a bright red mushroom head for quick visual identification. The zinc alloy actuator provides corrosion resistance in harsh environments. Requires manual reset after activation to prevent accidental restart.
Typical Applications:
- Emergency stop systems in CNC machinery
- Safety interlocks for conveyor systems
- Production line emergency shutdown controls
- Robotic cell safety circuits
- Hydraulic press safety mechanisms
Installation note:
Ensure full button travel clearance (minimum 5mm vertical space above actuator).
Perform monthly functional tests and lubricate rotating parts with silicone grease (ASG-15 recommended).
Safety notice:
This is a mechanical safety device - must be installed in series with electrical safety relays.
Never bypass or modify the reset mechanism.
| Property | Property Value |
|---|---|
| sku | S3PM05-P12A |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
