Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P13A
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM Mushroom Head Push Button Mechanical Valve S3PM05-P13A Specifications
- Model: S3PM05-P13A
- Type: 3/2-way normally closed (spring return)
- Operation type: Mechanical push-button with lockable mushroom head
- Port size: PT1/8 (G1/8 optional)
- Thread standard: ISO 228 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Max flow rate: 450 NL/min (ANR)
- Actuation force: 35N ±5N
- Stroke: 4mm ±0.5mm
- Body material: Nickel-plated brass
- Seal material: High-grade NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Weight: 82g ±3g
- Dimensions: 38mm(L) × 38mm(W) × 54mm(H)
- Mounting: Panel mounting with M18×1.5 thread
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency-stop style mechanical valve with oversized mushroom head for instant system shutdown. Features positive-lock mechanism requiring twist-release for resetting. Anti-vibration design maintains seal integrity in high-shock environments. Includes built-in tactile feedback and dual-stage O-ring sealing.
- Emergency stop systems in CNC machinery
- Safety interlocks for press machines
- Manual override in automated production lines
- Mobile hydraulic/pneumatic equipment controls
- Test bench safety cut-off valves
- Robotic cell emergency isolation
Installation note:
Requires 50mm front-panel thickness for secure mounting. Perform monthly
actuation tests to prevent sticking. Use thread sealant (PTFE tape recommended)
on port connections. Avoid lateral forces on actuator stem during operation.
| Property | Property Value |
|---|---|
| sku | S3PM05-P13A |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
