Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM06G
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM06G Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM06G
- Type: 3/2-way mechanical valve (Normally closed)
- Operation: Manual push-button with emergency stop function
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 350 NL/min (ANR)
- Actuation force: 50N ±10%
- Body material: Engineering plastic (PBT)
- Seal material: Oil-resistant NBR rubber
- Temperature range: -20℃ to 70℃ (-4°F to 158°F)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Mechanical life: ≥500,000 cycles
- Weight: 120g ±5% (including mounting hardware)
- Dimensions: 40mm(L) × 30mm(W) × 50mm(H)
- Mounting: Panel mounting with 18mm cutout diameter
- Reset type: Twist-to-release manual reset mechanism
Emergency safety valve with highly visible red mushroom head, designed for immediate system shutdown in critical situations. Features positive-locking mechanism with twist-release reset, requiring deliberate operator action to restart machinery. Anti-vibration design maintains seal integrity in high-shock environments.
- Emergency stop systems in press machines
- Safety interlocks for conveyor systems
- Production line emergency cutoff stations
- Robotic cell safety override controls
- Packaging machinery safety circuits
Installation notes:
- Mount within 600mm horizontal reach of operator position (EN ISO 13850 compliant)
- Ensure full button depression without obstructions (minimum 20mm clearance above)
- Use included sealing washer for IP65 rating maintenance
- Monthly functional testing recommended
- Inspect seal integrity every 6 months
- Lubricate reset mechanism annually with silicone grease
| Property | Property Value |
|---|---|
| sku | S3PM06G |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
