Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM06GG
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM06GG Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM06GG
- Type: Normally closed (NC) push-button mechanical valve
- Actuation type: Mushroom head emergency stop design
- Port size: 1/4" BSPP (G1/4)
- Operating pressure: 0.1–0.7 MPa
- Port thread standard: ISO 228 G-series
- Body material: Stainless steel (SUS303) with PPS coating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 60℃
- Operating force: ~5N (manual reset required)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Mechanical life: ≥1,000,000 cycles
- Weight: 215g ±5g
- Dimensions: 50mm(D) × 50mm(W) × 80mm(H)
- Mounting style: Panel mounting with M20 locknut
- Contact configuration: SPDT (1NO + 1NC)
Industrial-grade emergency stop valve featuring a bright red mushroom head with twist-to-reset functionality. Engineered for safety-critical applications with positive mechanical engagement and tactile feedback. The zinc-plated steel spring ensures reliable return action even in high-vibration environments. Includes dual O-ring seals for enhanced contamination resistance.
- Emergency stop systems on CNC machinery
- Safety interlocks for robotic workcells
- Press brake safety controls
- Assembly line emergency shutdown stations
- Packaging equipment safety circuits
Installation guidelines:
Mount within 45° of vertical orientation. Ensure minimum 30mm clearance around button perimeter.
For ISO 13849-1 compliance, use with dual-channel safety relays. Test monthly by performing full
depression and clockwise reset rotation.
| Property | Property Value |
|---|---|
| sku | S3PM06GG |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
