Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM06R
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM06R Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM06R
- Type: 3/2-way mechanical valve (spring return)
- Operation: Manual push-pull mushroom head (ISO 13850 compliant emergency stop design)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Flow capacity: 450 NL/min (ANR at 0.5 MPa)
- Actuation force: 30-50N (mechanical lock type)
- Weight: 220g ±5% (including mounting hardware)
- Dimensions: 48mm(L) × 48mm(W) × 82mm(H) (body only), 100mm(H) including button
- Seal material: HNBR rubber (oil & heat resistant)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Protection rating: IP67 (dustproof and waterproof)
- Mounting: Panel mounting (10-15mm panel thickness supported)
- Contact rating: 5A 250VAC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
Industrial-grade emergency stop valve featuring a bright red mushroom head with mechanical latching mechanism. The zinc alloy body with chrome plating resists corrosion in harsh environments. Integrated dual contacts enable both pneumatic circuit control and electrical signal feedback. Twist-release design for quick reset after activation.
- Production line emergency stop stations
- Injection molding machine safety systems
- Robotic cell safety interlocks
- Press machine two-hand control setups
- Food processing equipment emergency cutoff
Installation guidelines:
Mount within 45° of vertical position. Ensure full button travel (12mm stroke) isn't obstructed.
Use M4 stainless steel screws for panel fixation. Test monthly by full depression and rotation.
| Property | Property Value |
|---|---|
| sku | S3PM06R |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
