Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM06RG
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM06RG Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM06RG
- Type: 3/2-way normally closed (manual mechanical override)
- Port size: PT1/8 (G1/8 equivalent)
- Operating pressure: 0.05–0.85 MPa
- Flow capacity: 450 NL/min (at 0.5 MPa)
- Actuation force: 20-30N (ergonomic button design)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 185g ±5g
- Dimensions: 48mm(L) × 48mm(W) × 72mm(H)
- Mounting: Direct piping or panel mounting (M5 threaded holes)
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency-stop ready mechanical valve with oversized 38mm mushroom head for rapid system shutdown. Features tactile feedback with 5mm actuation stroke and lockable rotary collar for maintained position. Compatible with ISO 13850 safety standards. Requires 5-40μm filtered compressed air.
- Emergency stop circuits in production line machinery
- Safety interlocks for press machines
- Manual override in automated assembly systems
- Pneumatic system maintenance lockout/tagout stations
- Robotic cell safety gates
Installation note:
Mount within 45° of vertical position. Ensure full button depression clearance (≥15mm).
For safety systems, combine with dual valve configuration to meet PLd Cat.3 requirements.
| Property | Property Value |
|---|---|
| sku | S3PM06RG |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
