Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM08BG
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM08BG Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM08BG
- Type: 3/2-way mechanical valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃
- Button type: Mushroom head (emergency stop style)
- Actuation force: 45N ± 5N
- Protection rating: IP65 (dust-tight, protected against water jets)
- Mounting style: Panel mounting with M18 thread
- Weight: 180g ± 5g
- Dimensions: 42mm(L) × 42mm(W) × 60mm(H)
Emergency-stop mechanical valve with integrated manual override, featuring a bright red mushroom head for quick identification. The zinc-plated steel spring ensures reliable resetting after activation. Designed for safety-critical applications requiring immediate airflow cutoff. Includes dual-color position indicator (red/green) for visual status confirmation.
- Emergency stop circuits in CNC machinery
- Safety interlocks for automated production lines
- Pneumatic system manual override stations
- Training equipment safety controls
- Packaging line emergency shutdown systems
Installation note:
Requires 25mm minimum panel thickness for secure mounting.
Perform monthly functional tests - depress button fully until audible "click" confirms valve actuation.
Lubricate stem quarterly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | S3PM08BG |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
