Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM08G
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM Mushroom Head Push Button Mechanical Valve S3PM08G Specifications
- Model: S3PM08G
- Type: 3-position (3-way) mechanical locking valve with emergency stop function
- Actuation: Mushroom head push button with mechanical latching
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 450 L/min (ANR)
- Voltage compatibility: 24V DC/AC (for optional solenoid accessories)
- Contact capacity: 2NO+2NC contacts (silver alloy)
- Mechanical life: ≥500,000 cycles
- Operating force: 30-50N (actuation pressure)
- Weight: 198g ±5g
- Dimensions: 40mm(W) × 40mm(D) × 58mm(H)
- Housing material: Glass fiber reinforced PA66
- Seal material: Oil-resistant NBR
- Temperature range: -20℃ to +80℃
- Protection rating: IP65 (front face)/IP40 (housing)
- Reset method: Twist-to-release mechanism
Industrial-grade emergency stop valve featuring positive mechanical latching and bright yellow mushroom head for rapid visual identification. The dual-contact design ensures fail-safe circuit breaking, with integrated air pilot control for pneumatic system isolation. Rugged construction withstands high-vibration environments.
- Production line emergency stop stations
- Plastic injection molding machine safety systems
- Automated assembly line safety interlocks
- Packaging machinery emergency cutoff
- Robotic work cell safety perimeter controls
Installation guidelines:
Mount on 30-35mm thick panels using M20 mounting nut. Maintain ≥15mm
clearance behind button for full depression. Perform monthly mechanical
reset tests. Clean contact surfaces with IPA every 6 months.
Critical note:
Always connect to dual-channel safety relays when used in Category 4
safety circuits. Do not lubricate internal mechanisms - factory pre-lubricated
for life.
| Property | Property Value |
|---|---|
| sku | S3PM08G |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
