Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PM08GG
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM08GG Mushroom Head Push Button Mechanical Valve Specifications
- Model: S3PM08GG
- Type: 3/2-way normally closed (manual reset)
- Operation style: Mechanical latching with emergency stop function
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 750 L/min
- Actuation force: 35-45N
- Button diameter: Ø30mm
- Body material: Nickel-plated brass
- Seal material: HNBR rubber (-20℃ to 120℃)
- Weight: 218g ±3%
- Dimensions: 48mm(L) × 48mm(W) × 62.5mm(H)
- Mounting: Panel mounting with M20×1.5 thread
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Emergency stop valve with positive mechanical latching mechanism and large mushroom head for quick activation. Features double-sealed structure with anti-vibration design for industrial environments. Requires 5-7 bar lubricated or non-lubricated air (40μm filtration recommended). Manual reset requires 90° rotation of button cap.
- Production line emergency stop systems
- Press machine safety interlocks
- Robotic cell safety circuits
- Packaging equipment pneumatic emergency brakes
- Elevator door safety mechanisms
Installation guidelines:
Mount vertically with button accessible within 600mm floor level.
Maintain minimum 15mm clearance behind panel for reset operation.
Perform weekly manual tests for safety compliance.
| Property | Property Value |
|---|---|
| sku | S3PM08GG |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
