Airtac S3PM Mushroom Head Push Button Mechanical Valve S3PMM5G
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual operation with diverse actuator head configurations to accommodate varied operational conditions.
3. Poppet structure ensures superior sealing performance, smooth directional switching, and maintenance-free oil-free lubrication.
4. Multi-position mounting capability for flexible installation and user convenience.
5. S3C, S3D, S3Y, S3R, and S3L series employ metallic actuator heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves | Brand: Airtac | Series: S3PM Mushroom Head Push Button Style
AirTAC S3PM Mushroom Head Push Button Mechanical Valve S3PMM5G Specifications
- Model: S3PMM5G
- Type: 3/2-way normally closed (mechanical actuation)
- Port size: M5 (PT1/8 equivalent)
- Operating pressure: 0.05–0.7 MPa
- Operating force: 3.5N ±0.5N (manual actuation)
- Flow capacity: 120 NL/min (at 0.5 MPa)
- Body material: PA66 reinforced nylon
- Seal material: HNBR rubber (-20℃ to 80℃)
- Actuation type: Mechanical latching with emergency stop function
- Weight: 85g ±2g
- Dimensions: 38mm(L) × 38mm(W) × 54mm(H)
- Mounting: Panel mounting with M18×1.5 thread
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
Robust mechanical valve with integrated emergency stop mushroom head, featuring tactile feedback and positive locking mechanism. The bright yellow button enables quick visual identification in emergency situations. Designed for direct manual operation without electrical components, with corrosion-resistant construction for harsh environments.
- Emergency stop systems in automated production lines
- Safety interlocks for hydraulic/pneumatic presses
- Manual override in packaging machinery
- Material handling equipment safety controls
- Test bench pneumatic circuit isolation
Installation note:
Requires 18mm panel cutout diameter. Engage locknut with 8-10N·m torque.
Perform monthly mechanical reset tests to maintain emergency function reliability.
- Mounting collar: S3PM-CLAMP-M18
- Extension button: S3PM-EXTCAP-RED
- Protective cover: S3PM-COVER-IP69K
| Property | Property Value |
|---|---|
| sku | S3PMM5G |
| Position | 3-Port 2-Position |
| Port Size | M5 |
