Airtac S3V Vertical Roller Lever Mechanical Valve S3V06
1. The S3B, S3R, S3L, and S3V series require externally provided actuation force for directional switching, suitable for position sensing or limit switch applications;
2. S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual actuation with ergonomic actuator configurations, optimized for diverse application scenarios;
3. Poppet-style design ensures superior sealing performance, positive spool switching, and maintenance-free operation (no lubrication required);
4. Multi-position mounting options with simplified installation procedures;
5. S3C, S3D, S3Y, S3R, and S3L series incorporate durable metal actuators for enhanced longevity and operational stability.
Category: Mechanical Valves | Brand: AirTAC | Series: S3V
AirTAC S3V06 Vertical Roller Type Mechanical Valve Specifications
- Model: S3V06
- Type: 3/2-position normally closed (mechanical roller actuation)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–0.8 MPa
- Voltage compatibility: DC12V/24V, AC110V/220V (requires separate solenoid accessory)
- Weight: 195g ±5g
- Dimensions: 48mm(L) × 34mm(W) × 68mm(H)
- Flow capacity: CV 0.45 (Kv 0.41)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Actuation force: 2.5N minimum
- Response time: ≤50ms
- Protection rating: IP67 (dust/water resistant)
- Housing material: Reinforced PBT with glass fiber
Vertical roller-actuated mechanical valve featuring manual override capability and fail-safe spring return. The cam-follower design ensures precise position control with tactile feedback, while the stainless steel roller provides 500,000+ cycle durability. Optimized for vibration-prone environments with double-shielded bearings.
- Palletizer position locking mechanisms
- Conveyor belt emergency stop systems
- Robotic end-effector tool changers
- Packaging machine safety interlocks
- Textile machinery thread tension control
- Automated warehouse shuttle positioning
Installation guidelines:
Must be mounted vertically (±3° tolerance). Actuator roller requires periodic lubrication with ISO VG32 hydraulic oil.
Avoid side-loading forces exceeding 15N. For pneumatic connections, use 6mm OD tubing with 0.5mm wall thickness minimum.
Critical note:
Requires 5-40μm filtered compressed air with oil mist lubrication (ISO 8573-1:2010 Class 4.4.2).
Do not use with phosphate ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | S3V06 |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
