Airtac SAI63 Standard Cylinder SAI63AX10
The AirTAC Airtac SAI63 Standard Cylinder SAI63AX10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 10mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ63 mm
- Stroke10 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
About the Airtac SAI63 Standard Cylinder SAI63AX10
The AirTAC SAI63X10 is a double-acting ISO 15552 profile cylinder engineered for tight-space actuation. It provides 1559 N of push force at 0.5 MPa, utilizing a 10 mm stroke for high-impact clamping or short ejector movements.
Built with an extruded aluminum barrel, this model omits tie-rods for a cleaner exterior. The piston rod uses SUS420J2 stainless steel for superior corrosion resistance, and the PT tapered port ensures a robust pneumatic seal. As a non-standard stroke configuration, it is manufactured to order for specialized short-travel machinery.
Airtac SAI63 Standard Cylinder SAI63AX10 Technical Specifications
| Model | Airtac SAI63 Standard Cylinder SAI63AX10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI63 Standard Cylinder SAI63AX10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI63 Standard Cylinder SAI63AX10 Is Used
Short-Stroke Clamping
Delivers 1559 N of force in a 10 mm stroke for securing heavy workpieces during machining operations.
Compact Ejection
Fits into tight machine clearances to eject finished parts quickly without requiring a long extension.
Press Assembly
Performs localized pressing and riveting tasks where a full standard stroke would be too slow.
Is the Airtac SAI63 Standard Cylinder SAI63AX10 the Right Cylinder?
For slightly lower force requirements, stepping down to the SAI50 bore yields 982 N at 0.5 MPa. If your application requires holding a load without live air pressure, note that the SAI's adjustable air cushions only decelerate the piston at stroke end and do not function as a lock; consider the SAIL variant for fail-safe holding. This 10 mm stroke configuration is a made-to-order non-standard size. It provides a drop-in ISO 15552 mounting interface with a G3/8 PT port, compatible with FA/FB flanges or TC trunnion brackets, and requires no -S magnet unless sensors are needed.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI63 Standard Cylinder SAI63AX10 FAQ
At 0.5 MPa, the SAI63X10 generates 1559 N of push force and 1402 N of pull force. It can reach up to 2182 N at 0.7 MPa.
Yes, the SAI63X10 is dimensionally interchangeable per ISO 15552 standards, meaning it matches the mounting interface of other ISO 15552 profile cylinders.
