Airtac SAID200 Double Rod Cylinder SAID200X100S
The AirTAC Airtac SAID200 Double Rod Cylinder SAID200X100S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ200 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID200 Double Rod Cylinder SAID200X100S
The AirTAC SAID200X100-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 200 mm bore and 100 mm stroke. Because the piston rod exits both end covers, the annulus area is identical on extend and retract, yielding equal force and speed in both directions. This model generates 15079 N each way at 0.5 MPa.
Equipped with a magnet (-S), it supports AirTAC CMSE reed and DMSE electronic sensors housed within the dual-side barrel grooves. The standard carbon steel rod handles high side loads, while the PT tapered port thread ensures a robust pneumatic seal. Its through-rod design is ideal for mounting a secondary tool or cam on the rear extension.
Airtac SAID200 Double Rod Cylinder SAID200X100S Technical Specifications
| Model | Airtac SAID200 Double Rod Cylinder SAID200X100S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15080 N | 15080 N |
| 0.7 MPa | 21111 N | — |
| Max (@1.0 MPa) | 3075 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID200 Double Rod Cylinder SAID200X100S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID200 Double Rod Cylinder SAID200X100S Is Used
Symmetric-Force Transfer
Drives heavy workpiece shuttles requiring identical push and pull thrust, leveraging the 15079 N both-way capacity without speed fluctuations.
Twin-Station Actuation
Mounts a primary tool on the front rod end and a secondary mechanism or position flag on the rear protruding rod for synchronized dual operations.
Anti-Rotation Slides
Utilizes the twin-rod structure to guide heavy vertical loads securely, preventing piston drift and mechanical twisting during transit.
Is the Airtac SAID200 Double Rod Cylinder SAID200X100S the Right Cylinder?
Choose this 200 mm bore when an application requires massive, symmetric thrust (15079 N at 0.5 MPa) that a smaller neighbour like the SAID160X100-S (9425 N) cannot provide. A double-rod configuration is selected over a single-rod SAI when the mechanism demands dual-side guidance, anti-rotation resistance, or rear-rod position flagging. It uses the reduced SAID mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and omits FB, CA, CB, and CR.
As a dimensionally interchangeable ISO 15552 profile cylinder, it serves as a direct replacement for other standard double-rod units. Note that the adjustable air cushions only decelerate the piston near stroke end; they do not hold the load. If position holding without live pressure is required, use an external rod lock or pilot-operated check valve. Despite the 100 mm stroke, the 40 mm rod diameter requires checking external guide support to prevent rod-bearing bending under heavy loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID200 Double Rod Cylinder SAID200X100S FAQ
Because it is a double-rod cylinder, the effective area is the same on both sides. It generates 15079 N of force in both extend and retract directions at 0.5 MPa, and 21110 N at 0.7 MPa.
Yes, it is an extruded aluminum profile cylinder dimensionally interchangeable per ISO 15552. It serves as a direct replacement for other ISO 15552 double-rod cylinders, utilizing the standard SAID mounting interface.
