Airtac SCLF Front Locking Cylinder SCLF40X80-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF40X80-S Front Lock Cylinder Technical Details
- Model: SCLF40X80-S
- Type: Double-acting cylinder with mechanical locking
- Bore size: 40mm (±0.13mm tolerance)
- Stroke: 80mm (customizable 50-500mm)
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Spring-assisted wedge lock
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning type: Adjustable hydraulic buffer
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body (A6063-T5), CR/NBR seals
- Mounting style: ISO 15552 standard flange (MF1/MF2 options)
- Weight: 2.45kg (excluding accessories)
- Dimensions: 200mm(L) × 48mm(W) × 48mm(H) (at retracted position)
- Rod thread: M16×1.5 (external)
- Maximum locking force: 1,200N
- Response time: ≤0.5s (lock engagement)
Heavy-duty locking cylinder with fail-safe position retention, featuring dual piston seals and wear-resistant guide rings. The integrated mechanical lock activates automatically at stroke ends, maintaining position during power loss. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Vertical load holding in material handling systems
- Emergency stop positioning in press machines
- Precision fixturing for CNC machining centers
- Safety interlocks in automated assembly lines
- Position maintenance in tilt/rotation mechanisms
Installation guidelines:
Maintain 0.5-1mm clearance between lock mechanism and mating surface.
Lubricate guide shafts monthly with EP2 grease. Avoid side-load exceeding 50N during operation.
Critical note:
Lock engagement requires minimum 0.3MPa residual pressure.
Always depressurize system before manual override using the emergency release screw.
| Property | Property Value |
|---|---|
| sku | SCLF40X80-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 80 mm |
| Lock Position | Front Cover with Lock |
