Airtac SI100 Standard Cylinder SI100X100S
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X100S Standard Cylinder Specifications
- Model: SI100X100S
- Bore diameter: 100mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (standard) / optional NPT1/2
- Piston rod thread: M20×1.5
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel
- End caps: Cast iron
- Seal material: High-grade NBR + PU combination
- Weight: 12.5kg ±3%
- Dimensions: 328mm(L) × 125mm(W) × 125mm(H)
- Mounting type: Basic foot mounting (ISO 15552 standard)
- Protection rating: IP65 (standard) / IP67 (optional)
- Lubrication: Pre-lubricated (DIN 51506 VG32 oil equivalent)
A heavy-duty ISO 15552 compliant cylinder featuring double-acting operation with precision-machined components. The hard-anodized barrel surface provides exceptional wear resistance, while the triple-lip seal design ensures ≤0.5mm/s low creep speed stability. Requires 5-50μm filtered compressed air with ≤5mg/m³ oil content.
- Plastic injection molding machine clamp units
- Automotive welding fixture positioning
- Steel coil handling systems
- Paper press roller adjustment mechanisms
- Die-casting machine ejection systems
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use optional rod-end support brackets (accessory code: BR-100S). Lubricate piston rod weekly in high-cycle
applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | SI100X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
