Airtac SI125 Standard Cylinder SI125X100FTC
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X100FTC Standard Cylinder Specifications
- Model: SI125X100FTC
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 125 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Operating temperature: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: MF1/MF2 front flange & rear foot mounting (standard)
- Port size: G1/2 (BSPP thread)
- Piston rod thread: M24×1.5 (external)
- Rod material: Hard chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seals: NBR (standard), optional Polyurethane
- Weight: 8.7 kg (with standard accessories)
- Dimensions (L×W×H):
- Retracted length: 343 mm
- Extended length: 443 mm
- Body diameter: 125 mm
- Mounting base: 155×155 mm square pattern
- ISO stroke tolerance: ±1.5mm (for strokes ≤500mm)
- Max theoretical force:
- Thrust @0.6MPa: 7,358N
- Pull force @0.6MPa: 6,658N
High-force industrial cylinder with precision honed tube and multi-lip sealing system. Features dual adjustable cushions with shock absorber effect for smooth end-of-stroke deceleration. The TC suffix indicates triple chrome plating on piston rod for enhanced corrosion resistance in humid environments. Includes magnetic piston for sensor compatibility.
- Metal stamping press actuation systems
- Automotive assembly line clamping devices
- Heavy-duty material handling equipment
- Plastic injection molding machine ejectors
- Paper mill roller positioning mechanisms
Installation notes:
- Use M12×1.25 mounting bolts (grade 8.8 or higher)
- Maintain 0.5-1mm alignment tolerance during mounting
- Lubricate with ISO VG32 hydraulic oil if using non-lubricated air
- Install air filter regulator with auto-drain at upstream
Avoid side loads exceeding 150N. For vertical mounting,
use rod lock mechanism during maintenance. Maximum permissible lateral rod load: 1/20 of piston thrust.
| Property | Property Value |
|---|---|
| sku | SI125X100FTC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
