Airtac SI200 Standard Cylinder SI200X10
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X10 Standard Cylinder Specifications
- Model: SI200X10
- Type: ISO 15552 compliant single-acting/double-acting cylinder
- Bore size: 200 mm
- Stroke: 10 mm (customizable up to 2000 mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/4 (ISO 228 standard)
- Piston rod material: Chrome-plated steel (Cr-Mo)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.2 kg (without accessories)
- Dimensions: 292mm(L) × 220mm(W) × 220mm(H) (MF1 basic mounting)
- Rod end thread: M20×1.5
- Max theoretical force: 2827N @0.63MPa (double-acting)
- Speed range: 50–800 mm/s
- Mounting options: MF1 (front flange), MP2 (rear pivot), M3 (rear flange)
High-torque industrial cylinder with exceptional moment resistance, featuring corrosion-resistant construction and precision honed tube. The SI200X10's large bore design delivers superior thrust force for heavy-load applications. Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air (40μm filtration). Optional magnetic piston version available for position sensing.
- Injection molding machine ejectors
- Steel mill rolling equipment
- Automotive assembly line clamping
- Paper processing machinery
- Heavy-duty material handling systems
Installation notes:
- Align cylinder axis within ±0.2° of load path
- Maintain 0.5mm minimum clearance between rod end and load
- For vertical mounting, use lock nut (ANM-200) to prevent rod rotation
- Lubricate through air supply (ISO VG32 turbine oil recommended)
| Property | Property Value |
|---|---|
| sku | SI200X10 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <10mm> |
