Airtac SI200 Standard Cylinder SI200X1000
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1000 Standard Cylinder Specifications
- Model: SI200X1000
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: Ø200 mm
- Stroke: 1000 mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.2 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod thread: M45×2 (standard), alternative threads available
- Ambient temperature: -20℃ to 80℃
- Weight: 48.5 kg ±2% (without accessories)
- Dimensions:
- Total length: 1320 mm (stroke 1000 + 320mm end caps)
- Body diameter: Ø220 mm (aluminum alloy tube)
- Mounting base width: 245 mm (front flange pattern)
- Seal material: High-grade NBR with wear-resistant guide rings
- Speed range: 50–800 mm/s (optimal 200–500 mm/s)
- Protection rating: IP65 (wipers included)
- Mounting options: Basic, MF1 front flange, MB1 rear flange, MP4 trunnion
Heavy-duty industrial cylinder engineered for high-force linear motion in demanding environments. Features anodized aluminum construction with chromium-plated piston rod (hardness HRC 45-50). Integrated magnetizable piston for sensor compatibility. Optional stroke adjustment markers available.
- Press machine ejection systems
- Automotive assembly line clamping
- Steel coil handling equipment
- Packaging line heavy gate control
- Construction machinery actuators
Installation note:
For strokes over 800mm, use intermediate support brackets (ASD20 series recommended).
Lubricate through air supply (ISO VG32 hydraulic oil mist). Maintain 50mm clearance
behind rod end for full stroke operation.
| Property | Property Value |
|---|---|
| sku | SI200X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
