This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI200X100FA, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI200 Standard Cylinder SI200X100FA
The AirTAC Airtac SI200 Standard Cylinder SI200X100FA is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø200mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI200X100FA, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ200 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2.0
- StatusDiscontinued → SAI200X100FA
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI200 Standard Cylinder SI200X100FA
The AirTAC SI200X100FA is a discontinued double-acting ISO 15552 profile cylinder with a 200mm bore and 100mm stroke. Built for heavy-duty tasks, it delivers 15708 N of push force at 0.5 MPa through a G3/4 port. AirTAC replaced this legacy unit with the SAI200X100FA. This current-production direct maintains the exact ISO 15552 mounting interface, bore, stroke, output force, and FA flange accessory, fitting existing fixtures perfectly.
The SAI upgrade features a modernized piston seal with two Y-shaped one-way elements, ensuring low start-up pressure and extended lifespan. Note that this specific SKU lacks a magnet (-S), so it cannot accept CS1-B or DS1-B sensors. If high-temperature operation is needed, Viton H seals raise the limit to 150 C.
Airtac SI200 Standard Cylinder SI200X100FA Technical Specifications
| Model | Airtac SI200 Standard Cylinder SI200X100FA |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI200X100FA |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI200X100FA carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
The SAI200X100FA produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI200 Standard Cylinder SI200X100FA
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI200 Standard Cylinder SI200X100FA Is Used
Heavy Press Operations
Drives large stamping and forming presses requiring 15708 N of thrust at 0.5 MPa, utilizing the 200mm bore for massive impact force.
Large Mold Handling
Positions heavy injection molds and industrial tooling within manufacturing cells, relying on the rigid FA flange mounting interface.
Replacing the Airtac SI200 Standard Cylinder SI200X100FA with the SAI200X100FA
To replace the discontinued SI200X100FA, order the SAI200X100FA. Verify the ISO 15552 FA flange interface, 200mm bore, 100mm stroke, and G3/4 port (available in PT, G, or NPT threads). Because this SKU has no magnet, it cannot support position sensing; if switches are required, select an SAI equivalent with the S suffix. When sizing, the 200mm bore yields 15708 N push at 0.5 MPa; dropping to a 160mm bore reduces this to 10053 N. Remember, a standard cylinder does not hold load without live air—the cushion only decelerates. For load holding on air loss, use an external pilot check valve or explore the SAIL or BSAI lock variants.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI200X100FA
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI200 Standard Cylinder SI200X100FA FAQ
Yes, the AirTAC SI200X100FA is discontinued. The direct replacement is the SAI200X100FA. It shares the identical ISO 15552 mounting interface, 200mm bore, 100mm stroke, output force, G3/4 port, and FA flange, fitting directly into existing machinery.
This double-acting cylinder features a G3/4 port and an M36x2 rod thread. It delivers 15708 N push and 15080 N pull at 0.5 MPa, 21991 N push at 0.7 MPa, and a theoretical maximum of 3204 kgf at 1.0 MPa. It operates at speeds between 30-500 mm/s.
