Airtac SI200 Standard Cylinder SI200X100S
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X100S Standard Cylinder Specifications
- Model: SI200X100S
- Type: Double-acting ISO 6432 standard cylinder
- Bore size: 20mm (φ20)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/8 (ISO 228 standard)
- Piston speed: 50–800 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Mounting: Basic type (no built-in mounts)
- Weight: 0.6kg (excluding accessories)
- Dimensions: 160mm(L) × 32mm(Ø) × 32mm(W)
- Rod thread: M5×0.8 (male thread)
- Protection rating: IP65 (dust-tight & water jet resistant)
A precision-engineered ISO-compliant cylinder featuring dual adjustable air cushions for smooth deceleration. The hard-anodized barrel provides exceptional wear resistance, while the magnetic piston version (add "-M" suffix) enables position sensing. Requires ISO VG32 or equivalent hydraulic oil lubrication when operating above 0.5 MPa continuously.
- Automatic door mechanisms in cleanroom environments
- Precision clamping fixtures in CNC machining centers
- Material sorting gates in packaging lines
- Paper feed systems in printing machinery
- Component positioning in automotive assembly
Installation guidance:
For vertical mounting, install with rod facing downward to prevent
condensate accumulation. Maintain 0.5mm minimum clearance between
rod end and load during alignment. Use flexible couplings for
angular misalignment exceeding ±2°.
| Property | Property Value |
|---|---|
| sku | SI200X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
