Airtac SI200 Standard Cylinder SI200X1050SFA
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1050SFA Standard Cylinder Specifications
- Model: SI200X1050SFA
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 200 mm
- Stroke: 1050 mm
- Mounting style: Front/rear flange (FA series)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1" (standard), optional NPT1"
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (standard), optional FKM
- Weight: 38.6 kg (±2%)
- Dimensions:
- Extended length: 1465 mm
- Retracted length: 415 mm
- Body diameter: 230 mm
- Mounting flange thickness: 25 mm
- Rod end thread: M30×2 (male)
- Protection rating: IP65 (standard wiper)
High-capacity industrial cylinder designed for heavy-duty linear motion applications. Features oversized rod bearings for improved lateral load capacity and precision-guided piston movement. The anodized barrel resists corrosion in humid environments, while the triple-lip wiper seal prevents particulate ingress. Requires 40μm filtered air and recommended lubrication (oil mist 1-2 drops/m³).
- Automotive production line clamping fixtures
- Steel mill material handling systems
- Injection molding machine ejectors
- Shipbuilding positioning equipment
- Large-format CNC press brakes
Installation note:
Support rod end during horizontal mounting for strokes >800mm.
Allow 50mm clearance behind flange for cushion adjustment.
Pre-charge cushion chamber to 0.3MPa before initial operation.
| Property | Property Value |
|---|---|
| sku | SI200X1050SFA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1050mm |
