Airtac SI200 Standard Cylinder SI200X10FA
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X10FA Standard Cylinder Technical Details
- Model: SI200X10FA
- Bore size: Ø200 mm
- Stroke: 10 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Cushioning type: Adjustable air cushion (both ends)
- Piston speed: 50–800 mm/s
- Mounting style: Front flange mounting (ISO 15552 standard)
- Rod end type: Female thread M45×1.5
- Seal material: NBR + Polyurethane
- Ambient fluid: Clean dry air (40μm filtration required)
- Weight: 16.8 kg (without rod), 17.3 kg (with rod)
- Dimensions:
- Body length: 380 mm
- Extended length: 390 mm (stroke 10mm)
- Flange width: 240 mm
- Overall height (with rod): 310 mm
- Protection class: IP65 (rod seal)
- Lubrication: Pre-lubricated (oil-free operation possible)
- Standard compliance: ISO 15552, VDMA 24562
Heavy-duty industrial cylinder featuring reinforced aluminum alloy construction with chrome-plated piston rod (hardness HRC 45-50). Dual anti-rotation guide design ensures precise linear motion under high lateral load conditions. Integrated magnetizable piston enables position sensing compatibility. Corrosion-resistant base material withstands harsh environments.
- Metal stamping press ejection systems
- Automotive assembly line clamping devices
- Injection molding machine core-pull mechanisms
- Steel mill roller positioning systems
- Shipbuilding fixture actuators
Installation guidelines:
Use M16 mounting bolts (grade 8.8 or higher) with spring washers.
Maintain 0.5mm minimum alignment tolerance between rod and load.
Apply silicone grease (ASG-46) to rod before initial operation.
Allow 50mm rear clearance for cushion adjustment.
- Relubricate rod every 500 km of cumulative travel
- Inspect cushion seals every 1 million cycles
- Replace wear bands at 0.5mm rod play detection
| Property | Property Value |
|---|---|
| sku | SI200X10FA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <10mm> |
