Airtac SI40 Standard Cylinder SI40X1000SN
2. Features wear-resistant Y-shaped axial sealing structure with cushioning function, extended service life, and low friction resistance;
3. Aluminum square tube profile with anodized tie rods for superior corrosion resistance;
4. Built-in adjustable pneumatic cushioning at both ends;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AirTAC | Series: SI40
AirTAC SI40X1000SN Standard Cylinder Specifications
- Model: SI40X1000SN
- Bore size: 40mm
- Stroke: 1000mm
- Operation type: Double-acting
- Working pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Cushioning type: Adjustable rubber buffer + fixed cushion
- Piston rod material: Chrome-plated carbon steel
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 5.8kg ±2%
- Dimensions:
- Extended length: 1275mm
- Retracted length: 275mm
- Body width: 53mm
- Mounting height: 40mm
- Protection rating: IP65 (dust-tight & water jet resistant)
- Lubrication requirement: Pre-lubricated (ISO VG32 recommended for replenishment)
High-precision long-stroke pneumatic cylinder with reinforced guide structure, designed for heavy-duty linear motion applications requiring exceptional stability. Features wear-resistant composite seals and dual anti-rotation guides to prevent piston rod spin. Requires 5μm filtered air for optimal performance.
- Automated material handling systems
- Press machine ejection mechanisms
- Textile machinery tension control
- Automotive assembly line positioning
- Plastic injection molding machine gates
Installation note:
Support brackets required for strokes over 500mm. Maintain 0.5-1mm alignment tolerance during mounting.
Lubricate rod every 500km of cumulative travel. Avoid side load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SI40X1000SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
