Airtac SI63 Standard Cylinder SI63BX100
2. Piston sealing features dual-locked Y-type axial sealing structure with dust scraping capability, delivering extended service life and low friction resistance;
3. Aluminum tube with cross-shaped reinforcement and anodized tie rods for enhanced corrosion resistance;
4. Optimized cushion adjustment system with stable stroke control;
5. Multiple bore sizes and mounting accessories available for flexible configuration.
Category: Standard Cylinders | Brand: Airtac | Series: SI63
AirTAC SI63BX100 Standard Cylinder Specifications
- Model: SI63BX100
- Bore size: 63 mm
- Stroke: 100 mm
- Operating pressure: 0.1–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic MF1 flange mounting
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR (nitrile rubber)
- Tube material: Anodized aluminum alloy
- Weight: 2.3 kg (without accessories)
- Dimensions: 212mm(L) × 80mm(W) × 80mm(H) (at mid-stroke position)
- Max theoretical thrust: 307 kgf (at 0.63 MPa)
- Rod thread: M16×1.5 (ISO standard)
- Protection rating: IP40 (upgrade to IP67 with optional wiper)
A heavy-duty ISO 15552 compliant cylinder featuring double-acting operation and corrosion-resistant construction. The SI63BX100 combines 3-position adjustable pneumatic cushioning with a wear-resistant rod bearing, optimized for high-cycle applications. Includes built-in magnet for sensor compatibility (SI-M series). Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- Automotive welding fixture clamping
- Plastic injection molding ejectors
- Conveyor gate actuators
- Paper processing machinery
- Foundry equipment door operators
Installation note:
Maintain 0.1mm minimum parallel alignment between rod axis and load direction.
For vertical mounting, use counterbalance valves. Lubricate via port 2.5mm upstream
using ISO VG32 turbine oil. Max side load: 35N at full extension.
| Property | Property Value |
|---|---|
| sku | SI63BX100 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS304 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
