This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI63BX100S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI63 Standard Cylinder SI63BX100S
The AirTAC Airtac SI63 Standard Cylinder SI63BX100S is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø63mm bore and 100mm stroke, G3/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI63BX100S, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ63 mm
- Stroke100 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → SAI63BX100S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI63 Standard Cylinder SI63BX100S
The AirTAC SI63BX100S is a discontinued double-acting ISO 15552 profile cylinder with a 63mm bore and 100mm stroke. It delivers 1559N push and 1402N pull at 0.5MPa through a G3/8 port. The direct replacement is the SAI63BX100S, matching the interface, force, and mounting. The -B suffix denotes a SUS304 stainless steel piston rod for corrosion resistance.
The SAI upgrade features a two Y-shaped one-way piston seal for low start-up pressure. The -S magnet works with legacy CS1-B/DS1-B sensors, while the SAI uses current AirTAC switches. Note that cushions only decelerate; use SAIL or BSAI for load holding.
Airtac SI63 Standard Cylinder SI63BX100S Technical Specifications
| Model | Airtac SI63 Standard Cylinder SI63BX100S |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI63BX100S |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI63BX100S carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
The SAI63BX100S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI63 Standard Cylinder SI63BX100S
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 63 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI63 Standard Cylinder SI63BX100S Is Used
Stainless Rod Clamping
Ideal for packaging lines requiring washdown resistance, using the SUS304 rod to actuate clamping arms with 1559N force.
Replacing the Airtac SI63 Standard Cylinder SI63BX100S with the SAI63BX100S
To replace the SI63BX100S, order the SAI63BX100S. Confirm the ISO 15552 mounting interface (LB, FA, CA, TC), the G3/8 port, and the -S magnet. The SUS304 rod (-B) and Viton H high-temp seals must be specified. Sizing both ways: a 50mm bore yields 982N push at 0.5MPa, while an 80mm bore yields 2513N. If you need to hold a load without live air, a plain cylinder drifts; use the SAIL lock, BSAI clamp-lock, or an external pilot check valve. The SAIF variant adds a built-in valve for bores up to 100mm.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI63BX100S
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI63 Standard Cylinder SI63BX100S FAQ
Yes, the SI63BX100S is discontinued. The direct replacement is the SAI63BX100S. It is dimensionally interchangeable per ISO 15552, keeping the 63mm bore, 100mm stroke, G3/8 port, and SUS304 rod.
It features a G3/8 air port and M16x1.5 rod thread. Force output is 1559N push and 1402N pull at 0.5MPa, 2182N push at 0.7MPa, 2805N at 0.9MPa, and a theoretical max of 318kgf at 1.0MPa.
