Airtac SI63 Standard Cylinder SI63BX135S
2. Piston sealing features dual-locked Y-type axial sealing structure with dust scraping capability, delivering extended service life and low friction resistance;
3. Aluminum tube with cross-shaped reinforcement and anodized tie rods for enhanced corrosion resistance;
4. Optimized cushion adjustment system with stable stroke control;
5. Multiple bore sizes and mounting accessories available for flexible configuration.
Category: Standard Cylinders | Brand: Airtac | Series: SI63
AirTAC SI63BX135S Standard Cylinder Specifications
- Model: SI63BX135S
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 63 mm
- Stroke: 135 mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Port size: G1/4 (BSPP thread)
- Temperature range: -20℃ to 80℃
- Weight: 2.8 kg (without accessories)
- Dimensions: 301mm(L) × 80mm(W) × 80mm(H) (at mid-stroke position)
- Rod thread: M16×1.5 (external)
- Max theoretical thrust: 2800N @ 0.63MPa
- Lubrication: Pre-lubricated (relubrication interval: 3,000km travel distance)
The SI63BX135S features a robust aluminum body with wear-resistant guide rings, designed for high-cycle industrial applications. Its dual adjustable cushions minimize end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). The corrosion-resistant piston rod incorporates a multi-lip wiper seal to prevent particulate ingress.
- Automated packaging line pusher mechanisms
- Plastic injection molding machine ejectors
- CNC fixture clamping systems
- Automotive assembly line positioning devices
- Printing press paper feed mechanisms
Installation guidelines:
For vertical mounting, use M6 or larger mounting bolts with Loctite 243.
Maintain 0.5-1mm alignment tolerance between rod end and load.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | SI63BX135S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS304 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 135mm |
