Airtac SILF Front Locking Air Cylinder SILF125X50
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF125X50 Front Lock Cylinder Technical Specifications
- Model: SILF125X50
- Series: SILF Locking Cylinder Series
- Bore size: Ø125mm
- Stroke: 50mm
- Locking force: ≥12kN (at 0.5MPa)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting options: Basic type (MF1), Front flange (MF2), Rear flange (MF3)
- Port size: G1/2 (ISO228/1 standard)
- Operating temperature: -20℃ to 80℃
- Seal material: High-grade NBR with wear-resistant ring
- Weight: 10.8kg ±2% (excluding accessories)
- Dimensions:
- Total length (L): 298mm (at mid-stroke)
- Body diameter: Ø125mm
- Mounting base height: 22mm
- Rod end thread: M30×1.5
- Locking mechanism: Spring-assisted mechanical brake
- Response time: ≤0.3s (locking engagement)
- ISO standard: 15552 compliant
Heavy-duty locking cylinder with integrated position retention capability, featuring dual safety mechanisms (pneumatic + mechanical). The tungsten-coated piston rod and triple-lip seal design ensure over 3,000km service life under standard conditions. Requires 5-40μm filtered lubricated air (ISO8573-1 class 4).
- Vertical lifting systems requiring position hold (e.g., elevator safety brakes)
- Automated welding fixture positioning
- Press machine intermediate stroke locking
- Overhead material handling emergency stop systems
- Automotive assembly line pallet stops
Installation protocol:
Must maintain ≤0.5mm alignment tolerance during mounting.
Locking function activates only when pressure ≥0.3MPa.
Requires monthly lubrication (ISO VG32 equivalent oil).
Critical note:
Do NOT use as primary safety brake in vertical applications -
always install secondary mechanical safety device.
Locking mechanism requires manual release during maintenance.
| Property | Property Value |
|---|---|
| sku | SILF125X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
