Airtac SILF Front Locking Air Cylinder SILF160X450
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X450 Front Lock Cylinder Technical Details
- Model: SILF160X450
- Bore size: 160mm
- Stroke: 450mm (±0.5mm tolerance)
- Operating pressure: 0.1-1.0 MPa
- Lock holding force: ≥3,200N (at 0.5MPa)
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable hydraulic buffer
- Mounting style: MF1 series flange (ISO 15552 standard)
- Port size: G1/2 (NPT1/2 optional)
- Lock mechanism: Spring-loaded mechanical brake
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: HNBR with wear-resistant ring
- Weight: 12.5kg (excluding accessories)
- Dimensions: 730mm(L) × 200mm(W) × 200mm(H)
- Protection class: IP67 (wipers included)
- Lubrication: Pre-lubricated (Grease-free operation)
Heavy-duty lock cylinder with integrated fail-safe braking system, featuring dual-position sensing slots for magnetic switches. The three-stage locking mechanism ensures zero drift under 0.5MPa pressure loss. Precision ground rod (Ra≤0.2μm) with double lip seals prevents oil mist emission. Requires 40μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Press machine safety interlocks
- Automotive welding fixture position retention
- Die-casting mold clamping mechanisms
- Overhead crane emergency stop systems
- Vertical CNC tool changer positioning
Installation guidelines:
Lock engagement requires minimum 0.3MPa air pressure. Allow 0.5mm axial clearance during mounting.
Perform brake pad run-in (50-100 cycles at 0.3MPa) before full-load operation. Replace wear indicators when red mark becomes visible.
| Property | Property Value |
|---|---|
| sku | SILF160X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 450mm |
| Lock Position | Front Cover with Lock |
