Airtac SILF Front Locking Air Cylinder SILF160X500
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X500 Front Lock Cylinder Specifications
- Model: SILF160X500
- Type: Double-acting pneumatic cylinder with mechanical front lock
- Bore size: 160mm
- Stroke: 500mm (±1mm tolerance)
- Operating pressure: 0.2–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Locking force: 18,000 N (max at 0.5 MPa)
- Rod diameter: 45mm (chrome-plated steel)
- Mounting type: Standard MF1 flange mounting
- Lock activation: Air pressure ≥ 0.3 MPa required for lock release
- Temperature range: -20℃ to 80℃
- Seal material: NBR + PU hybrid seals
- Weight: 24.5 kg (excluding accessories)
- Dimensions: 1,150mm(L) × 210mm(W) × 210mm(H)
- Port size: G1/2 (BSPP thread)
- ISO standard: 15552 compliant
Heavy-duty locking cylinder designed for vertical load holding applications. Features dual safety mechanisms with mechanical lock engagement during pressure loss. The hardened piston rod and multi-lip seals ensure 5,000km+ service life under full load. Requires filtered air (40μm) with lubrication (ISO VG32).
- Press machine safety interlocks
- Automotive lifting platform position retention
- Die-casting mold clamping mechanisms
- Warehouse vertical shutter emergency brakes
- Steel coil handling equipment
Installation note:
Must be mounted vertically (±3° tolerance). Perform lock engagement test
at 0.5 MPa before operation. Lubricate guide bushings every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | SILF160X500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 500mm |
| Lock Position | Front Cover with Lock |
