Airtac SILF Front Locking Air Cylinder SILF160X600
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X600 Front Lock Cylinder Specifications
- Model: SILF160X600
- Type: Double-acting with mechanical lock
- Bore size: 160mm
- Stroke: 600mm
- Operating pressure: 0.1–0.8 MPa
- Locking force: ≥5,000N (at 0.5MPa)
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile)
- Mounting style: MF1 (front flange with rectangular base)
- Protection rating: IP66 (wipers included)
- Weight: 7.8kg (excluding accessories)
- Dimensions: 800mm(L) × 200mm(W) × 200mm(H)
Heavy-duty lock cylinder with integrated position retention mechanism, featuring wear-resistant chromium-plated piston rod and anti-rotation guide. The dual-safety lock engages automatically during pressure loss, maintaining position even under vibration. Requires 15-25μm filtered air with ISO VG32 lubricator.
- Injection molding machine clamp positioning
- Automated assembly line fixture locking
- Overhead material handling emergency stop
- Press brake tooling stabilization
- Die casting machine safety interlock
Installation note:
Align lock mechanism perpendicular to gravity vector. Perform lock engagement test at 0.3MPa before full operation.
Minimum 0.5MPa required for smooth unlocking sequence.
| Property | Property Value |
|---|---|
| sku | SILF160X600 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 600mm |
| Lock Position | Front Cover with Lock |
