Airtac SILF Front Locking Air Cylinder SILF160X700
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X700 Front Lock Cylinder Specifications
- Model: SILF160X700
- Type: Double-acting with mechanical lock (front side)
- Bore size: 160mm
- Stroke: 700mm
- Operating pressure: 0.1–0.8 MPa
- Operating medium: Dry air (lubricated or non-lubricated)
- Cushioning type: Adjustable pneumatic cushion
- Locking mechanism: Spring-loaded mechanical brake
- Port size: G1-1/2 (ISO standard)
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (Cr-Mo steel)
- Seals: NBR (Nitrile rubber)
- Weight: 24.8kg (without accessories)
- Dimensions:
- Extended length: 1,085mm
- Retracted length: 385mm
- Mounting face width: 200mm
- Overall height (with lock): 225mm
- Locking force: ≥5,000N (at 0.5MPa)
- Response time: ≤0.5s (locking engagement)
- ISO standard: 15552 compliant
Heavy-duty locking cylinder featuring fail-safe mechanical brake system for vertical/horizontal position holding. Precision ground rod with triple chrome plating ensures wear resistance. Integrated shock absorption reduces vibration during sudden stops. Requires 40μm filtered air and periodic lubrication (every 3 months minimum).
- Press machine safety interlocks
- Automated warehouse vertical lift positioning
- Die casting mold clamping mechanisms
- Wind turbine blade adjustment systems
- Elevator emergency braking units
Installation warning:
Locking mechanism requires manual release via safety lever before initial operation.
Maintain 0.3mm minimum clearance between lock unit and mounting bracket for thermal expansion.
- Inspect brake pads every 2,000km of stroke travel
- Replace return springs after 500,000 cycles
- Torque mounting bolts to 120N·m ±5%
| Property | Property Value |
|---|---|
| sku | SILF160X700 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 700mm |
| Lock Position | Front Cover with Lock |
