Airtac SILF Front Locking Air Cylinder SILF160X800
$754.18
Regular price
$761.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SILF160X800
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinders are categorized into two configurations: Front Cover Locking Type and Rear Cover Locking Type.
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
Installation requirements:
Maximum allowable side load 3% of thrust capacity. Requires monthly lubrication
maintenance. Avoid vertical downward mounting - if necessary, use auxiliary
safety chains. Lock engagement requires minimum 0.3MPa residual pressure.
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X800 Front Lock Cylinder Technical Details
- Model: SILF160X800
- Bore size: 160mm
- Stroke: 800mm
- Operating pressure: 0.1–1.0 MPa
- Locking mechanism: Mechanical wedge lock (auto-engage at stroke ends)
- Mounting type: MF1 front flange with integrated lock housing
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable pneumatic cushion + rubber buffer
- Temperature range: -10℃ to 80℃
- Rod material: Chrome-plated 45# steel
- Tube material: Aluminum alloy with hard anodization
- Seal material: NBR/PU combination
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 28.5kg ±2%
- Dimensions:
- Extended length: 1,230mm
- Retracted length: 430mm
- Flange width: 220mm
- Overall height (with lock): 205mm
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-stage locking force up to 12kN. The integrated wedge mechanism engages automatically at stroke ends, preventing unintended movement during power loss. Requires 5-7μm filtered air with ISO VG32 lubricator.
Industrial Applications:
- Press machine safety interlocks
- Vertical lifting systems in automotive assembly
- Mold clamping mechanisms in die-casting
- Overhead crane brake systems
- Satellite antenna positioning locks
Installation requirements:
Maximum allowable side load 3% of thrust capacity. Requires monthly lubrication
maintenance. Avoid vertical downward mounting - if necessary, use auxiliary
safety chains. Lock engagement requires minimum 0.3MPa residual pressure.
| Property | Property Value |
|---|---|
| sku | SILF160X800 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 800mm |
| Lock Position | Front Cover with Lock |
