Airtac SILF Front Locking Air Cylinder SILF160X900
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF160X900 Front Locking Cylinder Specifications
- Model: SILF160X900
- Series: SILF (Standard ISO Locking Cylinder)
- Bore size: 160 mm
- Stroke: 900 mm
- Operating pressure: 0.05–1.0 MPa
- Locking mechanism: Spring-applied pneumatic release
- Port size: G1/2 (ISO standard)
- Cushioning type: Adjustable air cushion at both ends
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃
- Mounting style: Standard MF1 flange or foot mounting
- Protection rating: IP54 (standard), IP67 optional
- Weight: 15.8 kg ±2%
- Dimensions: 1050mm(L) × 182mm(W) × 182mm(H)
- Rod thread: M30×1.5 (ISO 12240-2)
- Max locking force: 12,500 N (at 0.5 MPa)
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-stage sealing and chromium-plated piston rod. The integrated mechanical lock engages automatically upon pressure loss, preventing unintended movement. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- Vertical load holding in injection molding machines
- Safety positioning in automated material handling systems
- Press brake tooling fixation
- Overhead crane braking mechanisms
- Nuclear fuel rod handling equipment
Installation note:
Locking mechanism requires manual release during initial setup.
Maintain 0.5mm alignment tolerance during mounting. Lubricate with
ISO VG32 hydraulic oil monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SILF160X900 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | <900mm> |
| Lock Position | Front Cover with Lock |
