Airtac SILF Front Locking Air Cylinder SILF40X1000
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF40X1000 Front Locking Cylinder Specifications
- Model: SILF40X1000
- Type: Double-acting cylinder with mechanical locking (front position)
- Bore size: 40mm
- Stroke: 1000mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥850N (at 0.5MPa)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Lock mechanism: Wedge-type mechanical lock
- Mounting style: Standard MF1 (front flange) with optional accessories
- Port size: G1/8 (M5×0.8 optional)
- Piston speed: 50–800mm/s
- Lubrication: Pre-lubricated (DOP), maintenance-free design
- Weight: 5.8kg ±2%
- Dimensions: 1075mm(L) × 62mm(W) × 62mm(H) (excluding mounting accessories)
High-precision locking cylinder with integrated wedge mechanism for position retention during power loss. Features hard-anodized aluminum barrel and chrome-plated piston rod (SUS304 optional). The extended stroke design maintains stability through dual guide rods. Requires clean compressed air (ISO 8573-1:2010 Class 3-4-3).
- Vertical lifting systems in automated warehouses
- Precision clamping in CNC machining centers
- Position holding in automotive assembly robots
- Safety locking in press brake tooling
- Material handling equipment emergency stops
Installation note:
Ensure proper alignment of guide rods during assembly. Locking function activates only at full stroke end position.
Recommended 20% safety factor for load calculations. Lubricate sliding surfaces with ISO VG32 hydraulic oil if used in high-cycle applications (>500k cycles).
| Property | Property Value |
|---|---|
| sku | SILF40X1000 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
| Lock Position | Front Cover with Lock |
